- 2-speed transfer case w/3-position Control Trac shift-on-the-fly
- 4-wheel drive
- Limited slip rear axle
- 72 amp/hr (650-CCA) maintenance-free battery w/battery saver feature
- 110-amp alternator
- Integrated Class III trailer towing receiver-inc: 4-pin connector
- Front tow hooks
- 3275# capacity front coil springs/4128# capacity rear coil springs
- 3350# capacity front axle/4128# capacity rear axle
- Double wishbone front suspension w/coil-over shock
- Independent rear suspension
- Gas-charged shock absorbers
- Front/rear stabilizer bars
- P265/70R17 all-terrain SBR OWL tires
- Underbody-mounted full size BSW spare tire w/crank down feature
- 17" x 7.5" bright alloy wheels
- Steel spare wheel
- Variable assist pwr rack & pinion steering
- Pwr 4-wheel disc brakes
- 4-wheel anti-lock braking system
- 28.0 gallon fuel tank
- Luggage rack w/cross bars
- Painted body-color upper/Medium Dark lower front/rear step bumpers
- Running boards
- Medium Dark Platinum lower body-side cladding
- Medium Dark platinum grille
- Body-color door handles
- Fog lamps
- Autolamp feature-inc: auto on-off headlamp w/delay
- Black pwr heated fold-away mirrors w/security approach lamps
- Privacy glass-inc: rear doors, rear quarter windows, liftgate window
- Speed-sensitive intermittent windshield wipers
- Rear window intermittent wiper w/washer
- Rear liftgate w/flip-up glass
- Cloth 60/40 split front bench seat-inc: pwr driver seat, driver manual lumbar, manual recline
- Cloth 2nd row 40/20/40 split bench seat-inc: sliding center portion, recline & fold flat feature, carpeted seatbacks, easy-entry to 3rd row feature
- Cloth 3rd row 60/40 split bench seat-inc: fold flat feature
- Head restraints at all outboard seating positions
- Floor carpeting
- Front/rear carpeted floor mats
- Color-keyed polyurethane steering wheel
- Tilt steering column
- Pwr adjustable accelerator/brake pedals
- Analog instrumentation-inc: voltmeter, oil pressure, water temp, tachometer, trip odometer, compass, outside temp
- Pwr windows w/driver one-touch-down
- Pwr door locks
- Remote keyless entry w/(2) key fobs, illuminated entry, driver door keypad
- Cruise control
- SecuriLock passive anti-theft system
- Pwr accessory delay
- Manual air conditioning
- Auxiliary rear air conditioner w/heater, outside temp display
- Rear window defroster
- Premium electronic AM/FM stereo radio w/CD/cassette-inc: speed-compensated volume control, (4) speakers, RDS, clock, 120-watts
- Concealed antenna in RH quarter glass
- Locking glove box
- Cup holders-inc: (2) instrument panel, (4) door trim panels, (3) 3rd row quarter trim panels
- Ashtray mounted on instrument panel w/light
- Cigarette lighter
- Pwr point on instrument panel
- Cargo area pwr point
- Front & rear door map pockets
- Electrochromic rearview mirror
- Overhead console-inc: map lights, dual sunglasses holders, front aux HVAC controls, conversation mirror
- Color-keyed cloth headliner
- Dual color-keyed cloth sunvisors w/aux visors, dual illuminated mirrors
- Assist handles-inc: (1) front passenger, (2) second row
- Coat hooks-inc: (2) second row, (2) 3rd row
- Theatre dimming feature
- Lights-inc: glove box, front door approach, front dome/map, rear cargo, 2nd row map lights
- Driver & front passenger airbags-inc: driver seat position & load severity sensing
- 4-wheel anti-lock braking system
- Color-keyed lap/shoulder safety belts w/Beltminder system-inc: buckle pretensioners, load-limiting retractors
- Front/2nd row adjustable shoulder belt height
- Front/rear outboard head restraints
- Side intrusion door beams
- Child-proof rear door locks
5.4L (330) SOHC SEFI V8 "TRITON" ENGINE
- 5.4L (330) SOHC SEFI V8 TRITON ENGINE (STD)
- Locking/Limited Slip Differential
- Tow Hitch
- Tow Hooks
- Tires - Front All-Terrain
- Tires - Rear All-Terrain
- Conventional Spare Tire
- Power Steering
- 4-Wheel Disc Brakes
- Automatic Headlights
- Heated Mirrors
- Power Mirror(s)
- Privacy Glass
- Variable Speed Intermittent Wipers
- Power Driver Seat
- Cloth Seats
- Driver Adjustable Lumbar
- Rear Bench Seat
- Adjustable Steering Wheel
- Adjustable Pedals
- Power Windows
- Cruise Control
- Immobilizer
- Rear Defrost
- AM/FM Stereo
- Cassette
- CD Player
- Passenger Vanity Mirror
- Driver Air Bag
- Passenger Air Bag
- Child Safety Locks
- Rear A/C
- EPA Fuel Economy Est - City (MPG): 13
- EPA Fuel Economy Est - Hwy (MPG): 17
- Cold Cranking Amps @ 0° F (Primary): 650
- Maximum Alternator Capacity (amps): 110
- Maximum Alternator Watts: 1650
- Total Cooling System Capacity (qts): 21.0
- Gross Axle Wt Rating - Front (lbs): 3275
- Gross Axle Wt Rating - Rear (lbs): 4128
- Curb Weight - Front (lbs): 2868
- Curb Weight - Rear (lbs): 2821
- Gross Vehicle Weight Rating Cap (lbs): 7300
- Gross Combined Wt Rating (lbs): 14500
- Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs): 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 8650
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 865
- Suspension Type - Front: Coil Spring
- Suspension Type - Rear: Coil Spring
- Spring Capacity - Front (lbs): 3275
- Spring Capacity - Rear (lbs): 4128
- Axle Type - Front: Double Wishbone
- Axle Type - Rear: Independent
- Axle Capacity - Front (lbs): 3350
- Axle Capacity - Rear (lbs): 4128
- Axle Ratio (:1) - Front: 3.73
- Axle Ratio (:1) - Rear: 3.73
- Shock Absorber Diameter - Front (mm): 34.93
- Shock Absorber Diameter - Rear (mm): 34.93
- Stabilizer Bar Diameter - Front (in): 1.38
- Stabilizer Bar Diameter - Rear (in): 0.87
- Brake Type: Power
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 13.0 x 1.18
- Rear Brake Rotor Diam x Thickness (in): 13.5 x 0.9
- Front Tire Size: P265/70R17
- Rear Tire Size: P265/70R17
- Spare Tire Size: P265/70R17
- Front Tire Capacity (lbs): 2304
- Rear Tire Capacity (lbs): 2304
- Spare Tire Capacity (lbs): 2304
- Revolutions/Mile @ 45 mph - Front: 654
- Revolutions/Mile @ 45 mph - Rear: 654
- Revolutions/Mile @ 45 mph - Spare: 654
- Front Wheel Size (in): 17 x 7.5
- Rear Wheel Size (in): 17 x 7.5
- Spare Wheel Size (in): 17 x 7.5
- Front Wheel Material: Aluminum
- Rear Wheel Material: Aluminum
- Spare Wheel Material: Steel
- Steering Type: Variable Pwr Rack & Pinion
- Steering Ratio (:1), On Center: 20.5
- Turning Diameter - Curb to Curb (ft): 38.7
- Turning Diameter - Wall to Wall (ft): 40.5
- Frame Type: Front-to-Rear Boxed
- Fuel Tank Capacity, Approx (gal): 28
- Fuel Tank Location: Midship
- Wheelbase (in): 119.0
- Length, Overall w/rear bumper (in): 205.8
- Width, Max w/o mirrors (in): 78.7
- Height, Overall (in): 77.6
- Overhang, Front (in): 38.6
- Overhang, Rear w/bumper (in): 48.2
- Ground to Top of Load Floor (in): 35.5
- Ground Clearance, Front (in): 8.9
- Ground Clearance, Rear (in): 8.9
- Rear Door Opening Height (in): - TBD -
- Rear Door Opening Width (in): - TBD -
- Cargo Area Length @ Floor to Seat 1 (in): 87.2
- Cargo Area Length @ Floor to Seat 2 (in): 52.5
- Cargo Area Width @ Beltline (in): - TBD -
- Cargo Box Width @ Wheelhousings (in): 50.9
- Cargo Box (Area) Height (in): - TBD -
- Cargo Volume to Seat 1 (ft³): 110.5
- Cargo Volume to Seat 2 (ft³): 60.9
- Cargo Volume to Seat 3 (ft³): 20.6
- Passenger Capacity: 6
- Front Head Room (in): 39.7
- Front Leg Room (in): 41.2
- Front Shoulder Room (in): 63.4
- Front Hip Room (in): 63.0
- Second Head Room (in): 39.8
- Second Leg Room (in): 38.7
- Second Shoulder Room (in): 64.3
- Second Hip Room (in): 62.4
- Third Head Room (in): 38.2
- Third Leg Room (in): 36.3
- Third Shoulder Room (in): 60.1
- Third Hip Room (in): 54.5
- Vehicle Name: Ford Expedition
- Body Style: 4 Door
- Body Code: 119" WB
